起源の場所:
中国
ブランド名:
Hilink
証明:
CE Rohs
モデル番号:
HL-DF-SF-CVR について
| Wavelength | 1310nm | Rate | 40G/100G |
|---|---|---|---|
| Insertion Loss | ≤ 1dB | Technology | TFF (Thin Film Filter) |
| Insertion Loss | ≤ 2.7dB | Isolation | ≥35dB |
| Polarization Dependent Loss | ≤ 0.1ps | Return Loss | ≥ 45dB |
| TDL (dB) | ≤0.15dB | PMD (ps) | ≤0.055nm |
| Return Loss | ≥ 45dB | Directivity | ≥ 45dB |
| Power handling | ≤500mW | Fiber Type | SMF-28e |
| Connector | LC, SC, FC (UPC/APC) | Temperature | Operating: -40 to 85°C Storage: -40 to 85°C |
| Net Weight | LGX BOX: 0.5KG 4Slot 1u Rack: 2.5KG |
Dimensions (HxWxD) | LGX BOX: 214.5*150*20mm 4Slot 1u Rack: 44*440*160mm |
問い合わせを直接私たちに送ってください.
